Product Specifications
Packaging Type | Cartons, CANS, Bottles, Stand-up Pouch, Bags, Film, Pouch |
Weighing Bucket | 12 Buckets |
After-sales Service | Online support |
Function | FILLING, Sealing, Counting |
Certification | CE/ROHS |
Material | Stainless Steel 304/316 |
Key Selling Points | High-accuracy |
Customized support | OEM，ODM |
Applications
It is widely used in weighing granular, lumpy and flaky materials such as foodstuffs, pharmaceuticals, hardware, chemicals and plastics.
Suitable for weighing all kinds of small granular and small dosage products, such as traditional Chinese medicine tablets, pistachios, candies, coffee beans, chocolate chips and so on.
TECHNICAL PARAMETERS
Max. Weighing speed：120bpm
Weighing accuracy range：X(0.5)
Minimum scale：0.1g
Control system：MCU/PLC Dual system optional
Intelligent operation：Simple and beautiful operation interface
PRODUCT FEATURES
1. High speed and high precision:adopting high precision digital sensor, fast sampling speed and high precision.
2. Manual or automatic zeroing,and dynamic zero tracking are available.
3. The latest optimised sampling algorithm for improved weighing accuracy.
4. Multiple aggregate hopper discharge, effectively solving the clogging.
5. Intelligent fault detection and error reporting, accurate positioning to solve the problem.
6. Dual-function combination of weighing and counting improves counting accuracy.
Upper inlet hopper with double support is easy to adjust, and the lower outlet hopper is easy to dismantle design for easy cleaning.
1. Standard generalised parts design, strong interchangeability.
2. 70 degrees collector chute angle,zoned structure collector chute,favourable to the material smoothly sliding down, improve the speed.
3. Universal 1.6/2.5 litre hopper,adapted to the weighing of conventional materials, for a wide range of applications.
4. H-shaped chassis style, chassis and centre stand one-piece design, the whole machine structure is more stable, the appearance of more coordinated beauty.
