Specifications
Model | TY-JYH104P115-01-11 |
Max. Weighing | 500g |
Sorting Accuracy | ±0.3g |
Sorting Speed | 300 BPM |
HMI | 7" color touch screen |
Product Size | ≤1800mm(L)*120mm(W) |
Control System | High-speed A/D controller |
Pre-set Prod. No. | 99 |
Power Supply | AC220V±10% 50Hz/60Hz, 0.6KW |
Machine Dimension | 3592mm(L)*1174mm(W)*1508mm(H) |
Reject Device | Overturned device |
Working Condition | Temperature: 0℃~40℃; Humidity: 30%~95% |
Main Features
This machine stands out for its user-friendly design, strong adaptability, and cost-saving performance, perfectly matching the needs of poultry, aquatic, and agricultural product processing industries—whether for small-batch customization or large-scale mass production.
1. Strong Versatility: Wide Product Adaptation
Its standardized machine structure and universal HMI program eliminate the need for custom modifications for most products. It seamlessly handles weight sorting for diverse items, including:
Poultry (chicken legs/wings), aquatic products (shrimp, abalone), and agricultural goods (Chinese herbs, small fruits).
Products with weight ≤500g and size ≤12×18cm (covering 90% of small-to-medium-sized items in target industries).
Irregularly shaped products (e.g., curved trepang, uneven ginseng slices) without compromising sorting accuracy (±0.1g).
All contact parts use food-grade SUS304 stainless steel, complying with HACCP and FDA standards for cross-industry applicability.
2. Easy Product Switching: Fast Formula Recall
It can store 50+ sets of product formulas (e.g., sorting grades for chicken wings, shrimp, and wolfberries). When switching between products:
Operators only need to select the preset formula on the touch screen—no manual recalibration of weight grades or speed.
Switching time is ≤1 minute, significantly reducing downtime for small-batch, multi-SKU production (e.g., seasonal fruit grading or mixed aquatic product processing).
3. Intuitive Panel Operation: Low Training Cost
The 7-inch color touch screen features a smart, humanized interface:
Supports 8+ languages (English, Spanish, German, Chinese, etc.), adapting to multi-national teams in global factories.
Key functions (start/stop, grade adjustment, fault checking) are displayed with clear icons—no professional technical background required.
New operators can master basic operations in 30 minutes, cutting training time by 60% compared to complex industrial machines.
4. Easy Maintenance: Tool-Free Cleaning
The conveying belt adopts a modular, tool-free removable design:
The belt can be disassembled in 2–3 steps, allowing thorough cleaning of gaps (no hygiene dead corners) in 10–15 minutes.
Routine maintenance (e.g., belt replacement, sensor calibration) can be done by on-site staff—no need for third-party technicians, reducing maintenance costs by 30%.
5. High Efficiency & Economy: Labor & Cost Saving
It integrates multi-grade sorting (1–14 grades) and automatic weight checking in one workflow:
Sorting speed reaches up to 1,200 pieces/hour, replacing 3–5 manual sorters and reducing annual labor costs by 50–60%.
Automatic weight checking eliminates manual re-inspection, reducing mis-sorting rates to ≤0.1% and avoiding losses from unqualified products.
6. Flexible Augmentation: Customizable Expansion
Based on customer needs, additional equipment can be integrated to form a complete production line, such as:
Metal detectors (to remove contaminated products), date coders (for traceability), or conveying lifts (to connect upstream/downstream machines).
All add-ons use standardized interfaces, ensuring seamless integration without modifying the original machine structure—future-proofing your production line.
7. Adjustable Speed: Smooth & Damage-Free
Equipped with a frequency conversion control motor, the conveying speed can be adjusted between 0.5–3 m/min:
Slow down for fragile products (e.g., ripe strawberries, soft trepang) to avoid collision damage.
Speed up for sturdy items (e.g., chicken legs, hard-shelled shrimp) to boost efficiency.
Speed adjustment is done via the touch screen with real-time display, ensuring stable operation without sudden speed changes.
