Pet food zipper pouch packing machine main features:
Easy to operate and easy to replace the bag;
Low maintenance cost;
No bag prompting function;
Self-diagnosis function of open the bag failed (The bag can be reused); In that case, the machine will not fill and seal, it will re-take the bag;
Positioning (anti-dropping) function of hopper;
Warning function of cartridge heater fault;
Warning function of cylinder fault.
Pet food zipper pouch packing machine specification:
No | Feature | Description |
1 | Pouch material | Multilayer composite Premade Bag e.g: PET/PE |
2 | Pounch type | 3 side seal bag, stand up pouch, zipper bag, flat bottom pouch |
3 | Size range | 80mm≤W≤300mm
100mm≤L≤430mm |
4 | Speed | 0-15 bags/min |
5 | Sealing type | Straight grain, pitch is1mm (Optional reticulate) |
6 | Sealing width | 10mm(5--20mm can be customized) |
7 | Power supply | 220V, Single-phase, 50/60HZ, 1.2KW |
8 | Air pressure | 0.65Mpa |
9 | Air consumption | 0.3m³/min (Standard machine, no additional function) |
10 | Packaging dimension | 1860*600*1650mm(Export non-fumigation wooden case) |
Working flow:
giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product
Pet food zipper pouch packing machine applicable scope:
1. Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc
2. Granular type: granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer
3. Powder type: milk powder, glucose, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc
4. Liquid type: detergent, rice wine, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce
5. Other bagging materials
Associated equipment with Mini Doypack Machine:
1. Elevator: inclined elevator, Z type elevator, bowl elevator, single bucket elecator, etc.
2. FiIlling machine: multihead weigher, linear weigher, auger filler, etc.
3. Working platform: adjustable platform, simple platform, etc.
4. Exit conveyor / Check weigher / metal detector / Rotable table
